Description
Housing units PCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, P seals
INA
PCJY30-XL-N
Flanged housing unit
⌀30 × 62 × 30 mm
od EUR 36.19z VAT
netto EUR 29.42 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
PCJY30-XL-N—
EUR 36.19
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)PCJY30-XL-N#N1
EAN4012802807011
Wymiary⌀30 × 62 × 30 mm
Masa1.04 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
54 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- PCJY30-XL-N#N1
- EAN
- 4012802807011
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 62 mm
- Width B
- 30 mm
- Mass
- 1.04 kg
Load ratings and operation
- Dynamic load rating C
- 20700 N
- Static load rating C₀
- 11300 N
Full manufacturer specification44 parameters · expand
- Basic dynamic load rating
- 20700.0 N
- Basic static load rating
- 11300.0 N
- Bearing designation
- GAY30-XL-NPP-B
- Bearing in kit
- GAY30-XL-NPP-B
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Connection thread for lubrication
- M6
- Distance between mounting bolt centerlines (length)
- 82.5 mm
- Distance fixing bore
- 82.5 mm
- Distance raceway
- 20.0 mm
- Fatigue load limit, radial
- 480.0 N
- Fixing bore
- 11.5 mm
- Flange width
- 108.0 mm
- Groove
- N
- Height housing
- 31.0 mm
- Housing
- GEHCJ06-GG-N
- Housing height
- 108.0 mm
- Housing in kit
- PCJY30-XL-N
- Housing length
- 108.0 mm
- Housing material
- GG
- Housing opening
- combi
- Housing qty bolts
- 4
- Housing shape
- Viereck
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 41.0 mm
- Inner diameter bearing
- 30.0 mm
- Location on shaft
- Acc
- Marketing category
- XL
- Material
- GG
- Number of screwing holes
- 4.0
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 62.0 mm
- PFAS
- nein
- Protecting cap
- KASK06
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Sealing type
- LIP
- Shoulder diameter housing
- 85.0 mm
- Thickness of flange
- 12.0 mm
- Total height unit
- 41.0 mm
- Width of flats
- 3.0 mm
