Description
Flanged housing unit UKFL
FAG
UKFL207-J7
Flanged housing unit
⌀30 × 72 × 29 mm
od EUR 27.79z VAT
netto EUR 22.59 · cena detaliczna
EUR 37.05−25%
UKFL207-J7—
EUR 37.05
EUR 27.79Cheaper in larger quantities
| from 10 pcs | EUR 29.51 | −2% |
| from 50 pcs | EUR 28.91 | −4% |
| from 250 pcs | EUR 29.51 | −2% |
Last few (6)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)UKFL207-J7#N1
EAN4047643262064
Wymiary⌀30 × 72 × 29 mm
Masa1.28 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
52 parametersIdentification
- Manufacturer
- FAG
- Type
- Flanged housing unit
- Part number (SKU)
- UKFL207-J7#N1
- EAN
- 4047643262064
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 72 mm
- Width B
- 29 mm
- Mass
- 1.28 kg
Load ratings and operation
- Dynamic load rating C
- 27500 N
- Static load rating C₀
- 15300 N
Full manufacturer specification42 parameters · expand
- Basic dynamic load rating
- 27500.0 N
- Basic static load rating
- 15300.0 N
- Bearing designation
- UK207
- Bearing in kit
- UK207
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Distance between mounting bolt centerlines (length)
- 130.0 mm
- Distance fixing bore
- 130.0 mm
- Distance raceway
- 19.0 mm
- Fatigue load limit, radial
- 800.0 N
- Fixing bore
- 16.0 mm
- Flange width
- 90.0 mm
- Height bearing seat
- 80.5 mm
- Height flange
- 161.0 mm
- Height housing
- 34.0 mm
- Housing
- FL207
- Housing height
- 161.0 mm
- Housing in kit
- UKFL207-J7
- Housing length
- 90.0 mm
- Housing material
- GG
- Housing opening
- durchgehend
- Housing qty bolts
- 2
- Housing shape
- Oval
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 43.0 mm
- Inner diameter bearing
- 30.0 mm
- Location on shaft
- K
- Locking collar total width
- 43.0 mm
- Material
- GG
- Number of housings
- 1.0
- Number of screwing holes
- 2.0
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 72.0 mm
- Outside diameter eccentric locking collar
- 52.0 mm
- PFAS
- nein
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Sealing type
- LIP
- Thickness of flange
- 16.0 mm
