Description
Housing units PCFT, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals
INA
PCFT30-XL
Flanged housing unit
⌀30 × 62 mm
od EUR 28.97z VAT
netto EUR 23.55 · cena detaliczna
EUR 30.37−5%
PCFT30-XL—
EUR 30.37
EUR 28.97Cheaper in larger quantities
| from 10 pcs | EUR 24.19 | −2% |
| from 50 pcs | EUR 23.70 | −4% |
| from 250 pcs | EUR 23.45 | −5% |
In stock (43 pcs)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)PCFT30-XL#N1
EAN4012802791402
Wymiary⌀30 × 62 mm
Masa770 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
54 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- PCFT30-XL#N1
- EAN
- 4012802791402
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 62 mm
- Mass
- 770 g
Load ratings and operation
- Dynamic load rating C
- 20700 N
- Static load rating C₀
- 11300 N
Full manufacturer specification45 parameters · expand
- Basic dynamic load rating
- 20700.0 N
- Basic static load rating
- 11300.0 N
- Bearing designation
- GRAE30-XL-NPP-B
- Bearing in kit
- GRAE30-XL-NPP-B
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Connection thread for lubrication
- M6
- Distance between mounting bolt centerlines (length)
- 116.5 mm
- Distance fixing bore
- 116.5 mm
- Distance raceway
- 13.3 mm
- Fatigue load limit, radial
- 480.0 N
- Fixing bore
- 11.5 mm
- Flange width
- 80.0 mm
- Height bearing seat
- 71.0 mm
- Height flange
- 142.0 mm
- Height housing
- 22.3 mm
- Housing
- CFT06
- Housing height
- 142.0 mm
- Housing in kit
- PCFT30-XL
- Housing length
- 80.0 mm
- Housing material
- GG
- Housing opening
- durchgehend
- Housing qty bolts
- 2
- Housing shape
- Oval
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 40.0 mm
- Inner diameter bearing
- 30.0 mm
- Location on shaft
- Acc
- Marketing category
- XL
- Material
- GG
- Number of housings
- 1.0
- Number of screwing holes
- 2.0
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 62.0 mm
- Outside diameter locking collar
- 44.0 mm
- PFAS
- nein
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Sealing type
- LIP
- Shoulder diameter housing
- 80.0 mm
- Thickness of flange
- 12.0 mm
- Total height unit
- 40.0 mm
