Technical data

46 parameters

Identification

Manufacturer
INA
Type
Take-up housing unit
Part number (SKU)
THE30-XL#N1
EAN
4054372495878

Dimensions

Bore d
30 mm
Outside diameter D
62 mm
Mass
1.17 kg
Full manufacturer specification39 parameters · expand
Basic dynamic load rating
20700.0 N
Basic static load rating
11300.0 N
Bearing designation
GE30-XL-KTT-B
Bearing included in kit
GE30-XL-KTT-B
Bearing inner diameter
30.0 mm
Bearing outside diameter
62.0 mm
Bearing sealed
yes
Bearing seat height
72.0 mm
Bearing sort
RIBB
Bearing split
no
Category
XL
Distance shaft axis
72.0 mm
Height housing fixing side
40.0 mm
Housing
HE06
Housing height
85.0 mm
Housing included in kit
THE30-XL
Housing length
114.0 mm
Housing material
GG
Housing opening
durchgehend
Housing shape
Loch_unten
Housing sort
Take-up
Housing split
no
Housing total width
85.0 mm
Housing width
48.5 mm
Length of guidance face
40.0 mm
Length total
114.0 mm
Location on shaft
Acc
Lubrication connection thread
M6
Material
GG
Max. operating temperature
120.0 °C
Min. operating temperature
-20.0 °C
Number of housing bolts
1
PFAS
no
REACH
REACH compliant with declarable lead proportion
RoHS
RoHS compliant with declarable substances
Sealing type
LIP
Thread depth
24.0 mm
Thread fixing bore
M24
Width housing
32.0 mm

Classification

Manufacturer category
Housings › Radial Insert Ball Bearing Housing Units › Take Up Housing Units
eCl@ss class
23-05-16-03
UNSPSC
31171519

Description

Take-up housing units THE, cast iron housing, radial insert ball bearing with eccentric locking collar, T seals

For mounting this bearing

Accessories matching this item. All from our catalogue.

INA

THE30-XL

Common designation: THE30

Take-up housing unit

⌀30 × 62 mm

od EUR 54.58net

+ VAT 23% = EUR 67.13 gross

To orderdate to be confirmed

This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.

THE30-XL—
EUR 54.58

Cheaper in larger quantities

from 5 pcsEUR 53.49−2%
from 10 pcsEUR 52.94−3%
from 25 pcsEUR 51.85−5%
from 50 pcsEUR 50.76−7%

Brought in to order — we confirm the date after checking with the manufacturer.

Shipping within the EU: DHL, GLS, from EUR 13.16 net. Transit time 3–5 business days after dispatch. Shipping and returns →

Symbol (SKU)THE30-XL#N1
EAN4054372495878
Wymiary⌀30 × 62 mm
Masa1.17 kg

Buying for a company?

Open a business account →

Documentation

Datasheet (PDF)RoHS / REACH compliance declaration (PDF)

Opening a document for the first time can take up to a minute while the manufacturer prepares it.
