Technical data

24 parameters

Identification

Manufacturer
INA
Type
Yoke type track roller
Part number (SKU)
NA2203-2RSR#N1
EAN
4012802424102

Dimensions

Bore d
17 mm
Outside diameter D
40 mm
Mass
113 g

Load ratings and operation

Dynamic load rating C
8900 N
Static load rating C₀
13600 N
Sealing
2RSR
Full manufacturer specification14 parameters · expand
Bearing width
16.0 mm
Fatigue load limit, radial
1890.0 N
Inner ring raceway diameter
22.0 mm
Minimum chamfer
1.0 mm
Minimum mounting dimension
28.0 mm
Outer ring profile
R500
Outer ring width
15.8 mm
PFAS
no
Radius of outer ring outside profile
500.0 mm
REACH
REACH compliant
Relubrication
IR
RoHS
RoHS compliant
Sealing
2RSR
Speed on permanent grease lubrication
3000.0 1/min

Classification

Manufacturer category
Rolling and Plain Bearings › Track Rollers, Yoke Type-, Stud Type Track Rollers › Yoke Type Track Rollers
eCl@ss class
23-05-15-01
UNSPSC
31171512

Description

This needle roller bearing NA2203-2RSR carries radial loads through a single row of needle rollers running in a particularly thick-walled outer ring, combined with a needle roller and cage assembly and a separate inner ring. Bore diameter is 17.0 mm, outside diameter 40.0 mm, net mass 0.113 kg. The outer ring has no axial guidance, and the inner ring can be mounted independently of the outer ring and cage assembly. Sealing lips fitted on both sides provide radial sealing action, keeping contaminants out of the needle roller set and retaining lubricant within the bearing. Since the outer ring is not axially guided and the inner ring mounts separately, this needle roller bearing suits arrangements where the outer ring must move freely in the axial direction while the inner ring is fitted onto the shaft as a distinct assembly step.

The same bearing from other manufacturers (1 designations)

Same size and design — suffix notation differs between brands.

Comparison and details →

INA

NA2203-2RSR

original — this page

equivalent designation

NTN

NA2203LL

This is a dimensional and design equivalent, not the same product. If in doubt, ask us before ordering.

INA

NA2203-2RSR

Common designation: NA2203 2RS

Yoke type track roller

⌀17 × 40 mm

od EUR 30.90net

+ VAT 23% = EUR 38.01 gross

Last few (2)dispatch within 24 h
NA2203-2RSR—
EUR 30.90

Cheaper in larger quantities

from 5 pcsEUR 30.28−2%
from 10 pcsEUR 29.97−3%
from 25 pcsEUR 29.36−5%
from 50 pcsEUR 28.74−7%

Dispatched within 24 h from our own warehouse

Shipping within the EU: DHL, GLS, from EUR 13.18 net. Transit time 3–5 business days after dispatch. Shipping and returns →

Symbol (SKU)NA2203-2RSR#N1
EAN4012802424102
Wymiary⌀17 × 40 mm
Masa113 g

Buying for a company?

Open a business account →

Documentation

Datasheet (PDF)RoHS / REACH compliance declaration (PDF)
