Technical data
55 parametersIdentification
- Manufacturer
- FAG
- Type
- Take-up housing unit
- Part number (SKU)
- UKT206-J7#N1
- EAN
- 4054366901712
Dimensions
- Bore d
- 25 mm
- Outside diameter D
- 62 mm
- Mass
- 1.29 kg
Full manufacturer specification48 parameters · expand
- Basic dynamic load rating
- 20700.0 N
- Basic static load rating
- 11300.0 N
- Bearing designation
- UK206
- Bearing included in kit
- UK206
- Bearing inner diameter
- 25.0 mm
- Bearing outside diameter
- 62.0 mm
- Bearing sealed
- yes
- Bearing seat height
- 70.0 mm
- Bearing sort
- RIBB
- Bearing split
- no
- Distance guidance grooves
- 89.0 mm
- Distance shaft axis
- 70.0 mm
- Fixing bore
- 22.0 mm
- Height
- 102.0 mm
- Height housing fixing side
- 56.0 mm
- Height recess
- 37.0 mm
- Housing
- T206
- Housing height
- 102.0 mm
- Housing included in kit
- UKT206-J7
- Housing length
- 113.0 mm
- Housing material
- GG
- Housing opening
- durchgehend
- Housing shape
- Loch_seitlich
- Housing sort
- Take-up
- Housing split
- no
- Housing width
- 38.0 mm
- Length fixed link
- 10.0 mm
- Length guidance groove
- 57.0 mm
- Length total
- 113.0 mm
- Location on shaft
- K
- Locking collar total width
- 38.0 mm
- Lower distance guidance groove tolerance
- -0.5 mm
- Lower width guidance groove tolerance
- 0.0 mm
- Lubrication connection thread
- M6
- Material
- GG
- Max. operating temperature
- 100.0 °C
- Min. operating temperature
- -20.0 °C
- Number of housing bolts
- 1
- PFAS
- no
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Sealing type
- LIP
- Upper distance guidance groove tolerance
- 0.0 mm
- Upper width guidance groove tolerance
- 0.2 mm
- Width guidance groove
- 12.0 mm
- Width housing
- 28.0 mm
- Width housing fixing side
- 37.0 mm
- Width recess
- 16.0 mm
Classification
- Manufacturer category
- Housings › Radial Insert Ball Bearing Housing Units › Take Up Housing Units
- eCl@ss class
- 23-05-16-03
- UNSPSC
- 31171519
Description
This bearing housing accommodates a radial insert ball bearing mounted on an adapter sleeve, allowing the unit to slide within its supporting frame for linear motion adjustment. The cast iron housing has a bore diameter of 25.0 mm, an overall height of 102.0 mm, and a net mass of 1.29 kg. The basic dynamic load rating is 20700.0 N. The adapter sleeve fixing method permits mounting on plain shafting without a shoulder, and the sliding design compensates for thermal expansion or belt tensioning along the shaft axis. RSR seals on both sides of the bearing protect the raceway and rolling elements from dust and moisture ingress, while the grease-filled bearing reduces the need for frequent relubrication.
The same bearing from other manufacturers (5 designations)
Same size and design — suffix notation differs between brands.
FAG
UKT206-J7
original — this page
equivalent designation
NSK
UKT206
NSK
UKT206D1 + H2306X
NSK
UKT206J + H2306X
NTN
UKT206D1 + H2306X
SNR
UKT206H
This is a dimensional and design equivalent, not the same product. If in doubt, ask us before ordering.
