Technical data
52 parametersIdentification
- Manufacturer
- FAG
- Type
- Flanged housing unit
- Part number (SKU)
- UKFL208-J7#N1
- EAN
- 4047643261975
Dimensions
- Bore d
- 35 mm
- Outside diameter D
- 80 mm
- Width B
- 31 mm
- Mass
- 1.57 kg
Load ratings and operation
- Dynamic load rating C
- 34500 N
- Static load rating C₀
- 19800 N
Full manufacturer specification42 parameters · expand
- Basic dynamic load rating
- 34500.0 N
- Basic static load rating
- 19800.0 N
- Bearing designation
- UK208
- Bearing included in kit
- UK208
- Bearing inner diameter
- 35.0 mm
- Bearing outside diameter
- 80.0 mm
- Bearing sealed
- yes
- Bearing seat height
- 87.5 mm
- Bearing sort
- RIBB
- Bearing split
- no
- Distance between mounting bolt centerlines (length)
- 144.0 mm
- Fatigue load limit, radial
- 1030.0 N
- Fixing bore
- 16.0 mm
- Fixing bore spacing
- 144.0 mm
- Flange width
- 100.0 mm
- Height flange
- 175.0 mm
- Height housing
- 36.0 mm
- Housing
- FL208
- Housing height
- 175.0 mm
- Housing included in kit
- UKFL208-J7
- Housing length
- 100.0 mm
- Housing material
- GG
- Housing opening
- durchgehend
- Housing shape
- Oval
- Housing sort
- Flanged
- Housing split
- no
- Housing width
- 46.0 mm
- Location on shaft
- K
- Locking collar total width
- 46.0 mm
- Material
- GG
- Max. operating temperature
- 120.0 °C
- Min. operating temperature
- -20.0 °C
- Number of housing bolts
- 2
- Number of housings
- 1.0
- Number of screwing holes
- 2.0
- Outside diameter eccentric locking collar
- 58.0 mm
- PFAS
- no
- Raceway distance
- 21.0 mm
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Sealing type
- LIP
- Thickness of flange
- 16.0 mm
Classification
- Manufacturer category
- Housings › Radial Insert Ball Bearing Housing Units › Flanged Housings
- eCl@ss class
- 23-05-16-02
- UNSPSC
- 31171501
Description
Flanged housing unit UKFL
The same bearing from other manufacturers (4 designations)
Same size and design — suffix notation differs between brands.
FAG
UKFL208-J7
original — this page
equivalent designation
KOYO
UKFL208J + H2308X
NSK
UKFL208D1 + H2308X
NTN
UKFL208D1 + H2308X
SNR
UKFL208H
This is a dimensional and design equivalent, not the same product. If in doubt, ask us before ordering.
For mounting this bearing
Accessories matching this item. All from our catalogue.
UKFL208-J7
Flanged housing unit
⌀35 × 80 × 31 mm
od EUR 33.61net
+ VAT 23% = EUR 41.34 gross
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
Cheaper in larger quantities
| from 5 pcs | EUR 32.94 | −2% |
| from 10 pcs | EUR 32.60 | −3% |
| from 25 pcs | EUR 31.93 | −5% |
| from 50 pcs | EUR 31.26 | −7% |
Our own item, temporarily out of stock — write to us for a date.
Shipping within the EU: DHL, GLS, from EUR 13.18 net. Transit time 3–5 business days after dispatch. Shipping and returns →
Buying for a company?
Open a business account →Documentation
Datasheet (PDF)RoHS / REACH compliance declaration (PDF)Opening a document for the first time can take up to a minute while the manufacturer prepares it.
