Technical data
54 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- RATR35-XL#N1
- EAN
- 4012802823561
Dimensions
- Bore d
- 35 mm
- Outside diameter D
- 72 mm
- Mass
- 630 g
Load ratings and operation
- Dynamic load rating C
- 25500 N
- Static load rating C₀
- 15300 N
Full manufacturer specification45 parameters · expand
- Basic dynamic load rating
- 27500.0 N
- Basic static load rating
- 15300.0 N
- Bearing designation
- RAE35-XL-NPP-B
- Bearing included in kit
- RAE35-XL-NPP-B
- Bearing inner diameter
- 35.0 mm
- Bearing outside diameter
- 72.0 mm
- Bearing sealed
- yes
- Bearing seat height
- 44.5 mm
- Bearing sort
- RIBB
- Bearing split
- no
- Category
- XL
- Distance between mounting bolt centerlines (length)
- 100.0 mm
- Distance shaft axis
- 44.5 mm
- Fatigue load limit, radial
- 650.0 N
- Fixing bore spacing
- 100.0 mm
- Fixing square
- 10.5 mm
- Flange width
- 122.0 mm
- Height flange
- 122.0 mm
- Height housing
- 9.5 mm
- Housing
- FLAN72-MSTR
- Housing height
- 122.0 mm
- Housing included in kit
- RATR35-XL
- Housing length
- 105.6 mm
- Housing material
- SB
- Housing opening
- durchgehend
- Housing shape
- Dreieck_eckig
- Housing sort
- Flanged
- Housing split
- no
- Housing width
- 39.0 mm
- Load carrying capacity (housing)
- 6400.0 N
- Location on shaft
- Acc
- Material
- Steel sheet
- Max. operating temperature
- 120.0 °C
- Min. operating temperature
- -20.0 °C
- Number of housing bolts
- 3
- Number of housings
- 2.0
- Number of screwing holes
- 3.0
- PFAS
- no
- Pitch circle diameter (holes)
- 100.0 mm
- REACH
- REACH compliant
- RoHS
- RoHS compliant
- Sealing type
- LIP
- Shoulder diameter housing
- 81.0 mm
- Thickness of flange
- 2.5 mm
- Total height unit
- 31.9 mm
Classification
- Manufacturer category
- Housings › Radial Insert Ball Bearing Housing Units › Flanged Housings
- eCl@ss class
- 23-05-16-02
- UNSPSC
- 31171501
Description
This flanged bearing housing carries a bore diameter of 35.0 mm and is built from sheet steel with a three-bolt flange design. The unit uses an eccentric locking collar to secure the shaft and features P seals for protection against contamination. Basic dynamic load rating is 27500.0 N, and net mass is 0.63 kg. The eccentric locking collar allows secure fixation on the shaft without requiring additional fasteners, simplifying mounting and alignment during installation. The sheet steel construction keeps the housing lightweight while maintaining structural rigidity for the stated load rating, and the P seals limit ingress of dust and moisture into the bearing cavity, supporting stable operation under the specified dynamic load.
