Technical data
27 parametersIdentification
- Manufacturer
- INA
- Type
- Needle roller bearing
- Part number (SKU)
- NKI17/20-XL#N1>1
- EAN
- 4047643204422
- Cage
- Standard
Dimensions
- Bore d
- 17 mm
- Outside diameter D
- 29 mm
- Width B
- 20 mm
- Mass
- 54.16 g
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 19300 N
- Static load rating C₀
- 25500 N
- Limiting speed
- 20600 1/min
Full manufacturer specification14 parameters · expand
- Axial displacement
- 0.5 mm
- Cage
- Standard
- Category
- XL
- Coating
- without
- Fatigue load limit, radial
- 4500.0 N
- Inner ring raceway diameter
- 21.0 mm
- Max. operating temperature
- 120.0 °C
- Min. operating temperature
- -30.0 °C
- Minimum chamfer
- 0.3 mm
- PFAS
- no
- Radial internal clearance
- CN (group N)
- REACH
- REACH compliant
- Reference speed
- 11200.0 1/min
- RoHS
- RoHS compliant
Classification
- Manufacturer category
- Rolling and Plain Bearings › Roller Bearings › Needle Roller Bearings › Machined Needle Roller Bearings
- eCl@ss class
- 23-05-09-07
- UNSPSC
- 31171512
Description
Needle roller bearings NKI, light series
INA
NKI17/20-XL
Common designation: NKI17/20
Needle roller bearing
⌀17 × 29 × 20 mm
od EUR 18.13net
+ VAT 23% = EUR 22.30 gross
Temporarily out of stocktemporarily out of stock
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
NKI17/20-XL—
EUR 18.13
Cheaper in larger quantities
| from 5 pcs | EUR 17.77 | −2% |
| from 10 pcs | EUR 17.59 | −3% |
| from 25 pcs | EUR 17.22 | −5% |
| from 50 pcs | EUR 16.86 | −7% |
Our own item, temporarily out of stock — write to us for a date.
Shipping within the EU: DHL, GLS, from EUR 13.18 net. Transit time 3–5 business days after dispatch. Shipping and returns →
Symbol (SKU)NKI17/20-XL#N1>1
EAN4047643204422
Wymiary⌀17 × 29 × 20 mm
Masa54.16 g
