Description
Flanged housing unit GLCTEY
INA
GLCTEY30
Flanged housing unit
⌀30 × 62 × 30 mm
od EUR 26.52z VAT
netto EUR 21.56 · cena detaliczna
EUR 27.81−5%
GLCTEY30—
EUR 27.81
EUR 26.52Cheaper in larger quantities
| from 10 pcs | EUR 22.16 | −2% |
| from 50 pcs | EUR 21.71 | −4% |
| from 250 pcs | EUR 21.48 | −5% |
Last few (7)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)GLCTEY30#N1
EAN4012802804737
Wymiary⌀30 × 62 × 30 mm
Masa690 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
48 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- GLCTEY30#N1
- EAN
- 4012802804737
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 62 mm
- Width B
- 30 mm
- Mass
- 690 g
Load ratings and operation
- Dynamic load rating C
- 19500 N
- Static load rating C₀
- 11300 N
Full manufacturer specification38 parameters · expand
- Basic dynamic load rating
- 19500.0 N
- Basic static load rating
- 11300.0 N
- Bearing designation
- GAY30-XL-NPP-B
- Bearing in kit
- GAY30-XL-NPP-B
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Connection thread for lubrication
- M6
- Distance between mounting bolt centerlines (length)
- 90.5 mm
- Distance fixing bore
- 90.5 mm
- Distance raceway
- 11.4 mm
- Fixing bore
- 11.5 mm
- Flange width
- 84.0 mm
- Height flange
- 112.5 mm
- Housing
- GEHGLCTE06-GG
- Housing height
- 112.5 mm
- Housing in kit
- GLCTEY30
- Housing length
- 84.0 mm
- Housing material
- GG
- Housing opening
- durchgehend
- Housing qty bolts
- 2
- Housing shape
- Oval
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 32.4 mm
- Inner diameter bearing
- 30.0 mm
- Location on shaft
- Acc
- Material
- GG
- Number of screwing holes
- 2.0
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 62.0 mm
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing type
- LIP
- Thickness of flange
- 22.5 mm
- Total height unit
- 32.4 mm
