Description
Flanged housing unit GRRY..-VA
INA
GRRY30-VA
Flanged housing unit
⌀30 × 62 × 38.1 mm
od EUR 104.70z VAT
netto EUR 85.12 · cena detaliczna
EUR 109.77−5%
GRRY30-VA—
EUR 109.77
EUR 104.70Cheaper in larger quantities
| from 10 pcs | EUR 87.46 | −2% |
| from 50 pcs | EUR 85.67 | −4% |
| from 250 pcs | EUR 84.78 | −5% |
Last few (7)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)GRRY30-VA#N1
EAN4012802785388
Wymiary⌀30 × 62 × 38.1 mm
Masa600 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
55 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- GRRY30-VA#N1
- EAN
- 4012802785388
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 62 mm
- Width B
- 38.1 mm
- Mass
- 600 g
Load ratings and operation
- Dynamic load rating C
- 18700 N
- Static load rating C₀
- 10700 N
Full manufacturer specification45 parameters · expand
- Basic dynamic load rating
- 18700.0 N
- Basic static load rating
- 10700.0 N
- Bearing designation
- GYE30-KRR-B-VA
- Bearing in kit
- SUC206
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Distance between mounting bolt centerlines (length)
- 90.5 mm
- Fatigue load limit, radial
- 530.0 N
- Fixing square
- 10.5 mm
- Height bearing seat
- 56.35 mm
- Height flange
- 112.7 mm
- Height housing
- 9.0 mm
- Housing
- FLAN62-MSB-VA
- Housing (Part 2)
- FLAN62-MSA-VA
- Housing height
- 112.7 mm
- Housing in kit
- GRRY30-VA
- Housing length
- 112.7 mm
- Housing material
- SB
- Housing opening
- durchgehend
- Housing qty bolts
- 3-4
- Housing shape
- Rund
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 38.1 mm
- Inner diameter bearing
- 30.0 mm
- Load carrying capacity (housing)
- 5000.0 N
- Location on shaft
- Acc
- Material
- VA
- Number of housings
- 1.0
- Number of housings 2
- 1.0
- Number of screwing holes
- 3.0
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -35.0 °C
- Outer diameter bearing
- 62.0 mm
- Outside diameter eccentric locking collar
- 44.0 mm
- PFAS
- nein
- Pitch circle diameter (holes)
- 90.5 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing type
- LIP
- Shoulder diameter housing
- 71.0 mm
- Special material
- VA
- Thickness of flange
- 2.5 mm
- Total height unit
- 24.7 mm
