Description
Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
FAG
22217-E1-XL
Spherical Roller Bearing
⌀85 × 150 × 36 mm
od EUR 138.61z VAT
netto EUR 112.69 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
22217-E1-XL—
EUR 138.61
Cheaper in larger quantities
| from 15 pcs | EUR 108.18 | −4% |
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)22217-E1-XL#N1
EAN4026677808912
Wymiary⌀85 × 150 × 36 mm
Masa2.62 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
37 parametersIdentification
- Manufacturer
- FAG
- Type
- Spherical Roller Bearing
- Part number (SKU)
- 22217-E1-XL#N1
- EAN
- 4026677808912
- Cage
- JPA
Dimensions
- Bore d
- 85 mm
- Outside diameter D
- 150 mm
- Width B
- 36 mm
- Mass
- 2.62 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 305000 N
- Static load rating C₀
- 325000 N
- Limiting speed
- 5700 1/min
Full manufacturer specification24 parameters · expand
- Bore diameter outer ring
- 135.4 mm
- Bore type
- Z
- Cage
- JPA
- Design
- E1
- Diameter lubrication hole
- 3.2 mm
- Dynamic axial load factor
- 4.53
- Fatigue load limit, radial
- 39000.0 N
- Limiting value of Fa/Fr for the applicability of diff. Values of factors X and Y
- 0.22
- Marketing category
- XL
- Maximum diameter of housing shoulder
- 139.0 mm
- Maximum recess radius
- 2.0 mm
- Minimum chamfer dimension
- 2.0 mm
- Minimum diameter shaft shoulder
- 96.0 mm
- Operating temperature max.
- 200.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- Raceway diameter of the inner ring
- 99.7 mm
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- Reference speed
- 3450.0 1/min
- Relubrication feature
- Standard
- RoHS
- RoHS compliant
- Static axial load factor
- 2.97
- Width of lubricating groove
- 6.5 mm
