Technical data
22 parametersIdentification
- Manufacturer
- INA
- Type
- Adjusting gib
- Part number (SKU)
- VUS85280#N1
- EAN
- 4054372511585
Dimensions
- Width B
- 100 mm
- Mass
- 8.37 kg
Full manufacturer specification16 parameters · expand
- Adjustment max
- 0.5 mm
- Adjustment per screw revolution
- 0.075 mm
- Adjustment screw hexagon socket
- 12.0 mm
- Core hole
- 12.5 mm
- Fixing screws DIN ISO4762-12.9
- M10
- For linear roller bearing
- RUS85280
- Height min
- 38.0 mm
- Length max
- 314.0 mm
- Locking/extraction screw hexagon socket
- 4.0 mm
- Lower tolerance
- 0.1 mm
- Max
- 10.0 mm
- PFAS
- no
- REACH
- REACH compliant for SVHC free linear products (acc to PL responsibles)
- Size code
- 85280
- Tightening torque
- 83.0 Nm
- Upper tolerance
- 0.1 mm
Classification
- Manufacturer category
- Linear Motion › Monorail Guidance Systems › Linear Recirculating Roller Bearing Units › Accessories
- eCl@ss class
- 23-30-90-90
- UNSPSC
- 31171506
INA
VUS85280
Adjusting gib
od EUR 6,383.03net
+ VAT 23% = EUR 7,851.13 gross
To orderdate to be confirmed
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
VUS85280—
EUR 6,383.03
Cheaper in larger quantities
| from 5 pcs | EUR 6,127.71 | −4% |
| from 10 pcs | EUR 6,063.88 | −5% |
| from 25 pcs | EUR 5,936.22 | −7% |
| from 50 pcs | EUR 5,808.55 | −9% |
Brought in to order — we confirm the date after checking with the manufacturer.
Shipping within the EU: DHL, GLS, from EUR 13.16 net. Transit time 3–5 business days after dispatch. Shipping and returns →
Symbol (SKU)VUS85280#N1
EAN4054372511585
Masa8.37 kg
Buying for a company?
Open a business account →Documentation
Datasheet (PDF)RoHS / REACH compliance declaration (PDF)Opening a document for the first time can take up to a minute while the manufacturer prepares it.
