Description
Housing units RCJTZ, two-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, R seals
INA
RCJTZ25-XL
Flanged housing unit
⌀25 × 52 mm
od EUR 35.72z VAT
netto EUR 29.04 · cena detaliczna
EUR 47.00−24%
RCJTZ25-XL—
EUR 47.00
EUR 35.72Cheaper in larger quantities
| from 10 pcs | EUR 37.45 | −2% |
| from 50 pcs | EUR 36.68 | −4% |
| from 250 pcs | EUR 36.30 | −5% |
Last few (5)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)RCJTZ25-XL#N1
EAN4054371842239
Wymiary⌀25 × 52 mm
Masa760 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
56 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- RCJTZ25-XL#N1
- EAN
- 4054371842239
Dimensions
- Bore d
- 25 mm
- Outside diameter D
- 52 mm
- Mass
- 760 g
Load ratings and operation
- Dynamic load rating C
- 14900 N
- Static load rating C₀
- 7800 N
Full manufacturer specification47 parameters · expand
- Basic dynamic load rating
- 14900.0 N
- Basic static load rating
- 7800.0 N
- Bearing designation
- GE25-XL-KRR-B
- Bearing in kit
- GE25-XL-KRR-B
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Connection thread for lubrication
- M6
- Diameter spigot
- 60.0 mm
- Diameter spigot clearance
- h8
- Distance between mounting bolt centerlines (length)
- 99.0 mm
- Distance fixing bore
- 99.0 mm
- Distance raceway
- 19.0 mm
- Fatigue load limit, radial
- 370.0 N
- Fixing bore
- 11.5 mm
- Flange width
- 70.0 mm
- Height flange
- 124.0 mm
- Height housing
- 28.5 mm
- Height spigot
- 3.5 mm
- Housing
- GEHCJTZ05-GG
- Housing height
- 124.0 mm
- Housing in kit
- RCJTZ25-XL
- Housing length
- 70.0 mm
- Housing material
- GG
- Housing opening
- durchgehend
- Housing qty bolts
- 2
- Housing shape
- Oval
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 46.0 mm
- Inner diameter bearing
- 25.0 mm
- Location on shaft
- Acc
- Locking collar total width
- 44.5 mm
- Marketing category
- XL
- Material
- GG
- Number of screwing holes
- 2.0
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 52.0 mm
- Outside diameter eccentric locking collar
- 37.5 mm
- PFAS
- nein
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Sealing type
- LIP
- Shoulder diameter housing
- 70.0 mm
- Thickness of flange
- 12.0 mm
- Total height unit
- 46.0 mm
