Description
Flanged housing unit PCJT..-TV
INA
PCJT20-TV-FA125.5
Flanged housing unit
⌀20 × 47 mm
od EUR 46.47z VAT
netto EUR 37.78 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
PCJT20-TV-FA125.5—
EUR 46.47
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)PCJT20-TV-FA125.5#N1
EAN4012802831825
Wymiary⌀20 × 47 mm
Masa270 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
52 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- PCJT20-TV-FA125.5#N1
- EAN
- 4012802831825
Dimensions
- Bore d
- 20 mm
- Outside diameter D
- 47 mm
- Mass
- 270 g
Load ratings and operation
- Dynamic load rating C
- 12400 N
- Static load rating C₀
- 6000 N
Full manufacturer specification43 parameters · expand
- Basic dynamic load rating
- 12400.0 N
- Basic static load rating
- 6000.0 N
- Bearing designation
- GRAE20-NPP-B-FA107/125.5
- Bearing in kit
- GRAE20-NPP-B-FA107/125.5
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Connection thread for lubrication
- 1/4"-28 UNF
- Distance between mounting bolt centerlines (length)
- 90.0 mm
- Distance fixing bore
- 90.0 mm
- Distance raceway
- 15.4 mm
- Fixing bore
- 11.0 mm
- Flange width
- 63.8 mm
- Height bearing seat
- 57.0 mm
- Height flange
- 114.0 mm
- Height housing
- 26.5 mm
- Housing
- CJT04-TV
- Housing height
- 114.0 mm
- Housing in kit
- PCJT20-TV-FA125.5
- Housing length
- 64.8 mm
- Housing material
- PL
- Housing opening
- combi
- Housing qty bolts
- 2
- Housing shape
- Oval
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 26.5 mm
- Inner diameter bearing
- 20.0 mm
- Location on shaft
- Acc
- Manufacturing instruction
- FA125.5
- Material
- TV
- Number of housings
- 1.0
- Number of screwing holes
- 2.0
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -35.0 °C
- Outer diameter bearing
- 47.0 mm
- Outside diameter locking collar
- 33.0 mm
- PFAS
- nein
- Protecting cap
- KASK04
- Sealing type
- LIP
- Shoulder diameter housing
- 63.8 mm
- Thickness of flange
- 11.4 mm
- Total height unit
- 38.9 mm
