Description
Needle roller/axial cylindrical roller bearings NKXR, axial component, single direction, to DIN 5429, without end cap, for oil lubrication
INA
NKXR25-XL
Needle roller/axial cylindrical roller bearing
⌀25 × 37 mm
od EUR 56.06z VAT
netto EUR 45.58 · cena detaliczna
NKXR25-XL—
EUR 56.06
Cheaper in larger quantities
| from 250 pcs | EUR 41.02 | −10% |
Last few (3)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)NKXR25-XL#N1
EAN4012802736014
Wymiary⌀25 × 37 mm
Masa119.17 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
33 parametersIdentification
- Manufacturer
- INA
- Type
- Needle roller/axial cylindrical roller bearing
- Part number (SKU)
- NKXR25-XL#N1
- EAN
- 4012802736014
- Tolerance class
- PN
Dimensions
- Bore d
- 25 mm
- Outside diameter D
- 37 mm
- Mass
- 119.17 g
Load ratings and operation
- Dynamic load rating C
- 21300 N
- Static load rating C₀
- 30500 N
- Limiting speed
- 8500 1/min
- Sealing
- Without
Full manufacturer specification21 parameters · expand
- Basic dynamic load rating, axial
- 33500.0 N
- Basic static load rating, axial
- 76000.0 N
- Bore diameter of shaft washer
- 25.0 mm
- Distance to lubrication hole
- 9.5 mm
- Fatigue load limit, axial
- 7200.0 N
- Fatigue load limit, radial
- 5400.0 N
- Height
- 30.0 mm
- Marketing category
- XL
- Maximum outerside diameter flange
- 42.1 mm
- Maximum recess radius
- 0.6 mm
- Minimum chamfer dimension
- 0.6 mm
- Mounting dimension shaft shoulder
- 37.7 mm
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- REACH
- REACH conform
- Reference speed
- 3400.0 1/min
- RoHS
- RoHS compliant
- Sealing
- Without
- Suitable inner rings IR
- IR20X25X20-XL
- Width of the axial brearing component
- 11.0 mm
