Description
Securing plate MS, locknut, DIN5406
FAG
MS3152
Securing plate
od EUR 24.94z VAT
netto EUR 20.28 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
MS3152—
EUR 24.94
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)MS3152#N1
EAN4012801315098
Masa59 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
17 parametersIdentification
- Manufacturer
- FAG
- Type
- Securing plate
- Part number (SKU)
- MS3152#N1
- EAN
- 4012801315098
Dimensions
- Mass
- 59 g
Full manufacturer specification12 parameters · expand
- Diameter fixing hole spacing
- 11.0 mm
- Hexagonal bolt
- M10x20
- Hight retaining ring
- 12.0 mm
- Hight retaining slot
- 9.0 mm
- Length retaining ring
- 24.0 mm
- Mounting torque screw
- 51.0 Nm
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Thickness
- 4.0 mm
- Width inner retaining ring
- 25.5 mm
- Width retaining slot
- 26.0 mm
