Description
Plummer block housing, split, for spherical roller bearings, oil-lubrication
FAG
LOE312-N-AL-L
Plummer block housing
⌀60 × 130 × 220 mm
od EUR 4,515.34z VAT
netto EUR 3,671.01 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
LOE312-N-AL-L—
EUR 4,515.34
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)LOE312-N-AL-L#N1
EAN4026677548481
Wymiary⌀60 × 130 × 220 mm
Masa37.00 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
48 parametersIdentification
- Manufacturer
- FAG
- Type
- Plummer block housing
- Part number (SKU)
- LOE312-N-AL-L#N1
- EAN
- 4026677548481
Dimensions
- Bore d
- 60 mm
- Outside diameter D
- 130 mm
- Width B
- 220 mm
- Mass
- 37.00 kg
Full manufacturer specification40 parameters · expand
- Bearing sort
- SRB
- Bearing split
- No
- Bore distance width
- 80.0 mm
- Center heigth
- 125.0 mm
- Distance between mounting bolt centerlines (length)
- 310.0 mm
- Distance between mounting bolt centerlines (width)
- 80.0 mm
- Distance fixing bore
- 310.0 mm
- Height
- 220.0 mm
- Height bearing seat
- 125.0 mm
- Heigth base
- 45.0 mm
- Housing height
- 220.0 mm
- Housing length
- 370.0 mm
- Housing material
- GG
- Housing opening
- Geschlossen
- Housing qty bolts
- 4
- Housing shape
- Fuss_lang
- Housing sort
- Plummer
- Housing split
- Ja
- Housing width
- 220.0 mm
- Inner diameter bearing
- 60.0 mm
- Length base
- 370.0 mm
- Length slot
- 30.0 mm
- Location collar width
- 55.0 mm
- Location on shaft
- Fix
- Maximum height oil level
- 65.0 mm
- Minimum height oil level
- 50.0 mm
- Oil quantity first filling
- 1.0 l
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 130.0 mm
- PFAS
- nein
- Shaft diameter
- 60.0 mm
- Shaft diameter shoulder
- 65.0 mm
- Size of fixing screws
- M16
- Thread shaft nut
- M60X2
- Total width
- 220.0 mm
- Wall thickness
- 18.0 mm
- Width base
- 130.0 mm
- Width housing body
- 140.0 mm
- Width slot
- 20.0 mm
