Technical data

19 parameters

Identification

Manufacturer
INA
Type
Yoke type track roller
Part number (SKU)
LFR5201-10-2Z#N1N
EAN
4012802794342

Dimensions

Mass
60 g

Load ratings and operation

Sealing
2Z
Full manufacturer specification13 parameters · expand
Diameter of rolling
32.25 mm
Effective dynamic load rating as track roller (radial)
8400.0 N
Effective static load rating as track roller (radial)
5000.0 N
Limit of fatigue load
250.0 N
Permissible dynamic limit load
4750.0 N
Permissible static limit load
10000.0 N
PFAS
no
Possible roller-pin combination
siehe Katalog: LF1
REACH
REACH compliant for SVHC free linear products (acc to PL responsibles)
RoHS
RoHS compliant
Sealing
2Z
Size
5201
Width, inner ring
15.9 mm

Classification

Manufacturer category
Linear Motion › Track Roller Guidance Systems › Track Rollers (Yoke Type)
eCl@ss class
23-30-90-90
UNSPSC
31162701

Description

Guides linear or rotating motion along a track by rolling contact, transmitting radial load through the outer ring profile while the inner bore mounts directly on a shaft or stud. The bearing carries a net mass of 60.0 g and is fitted with 2Z sealing, shielding the raceway on both sides from contamination without contact friction. The 2Z shielding keeps the track roller running with consistent internal conditions where exposure to dust or debris would otherwise affect rolling performance. As a yoke type track roller, LFR5201-10-2Z is suited for applications requiring a compact rolling element with a fixed outer contour, mounted where axial space is limited and the load path runs through the yoke-style outer surface.

INA

LFR5201-10-2Z

Yoke type track roller

od EUR 14.89net

+ VAT 23% = EUR 18.31 gross

In stock (269 pcs)dispatch within 24 h
LFR5201-10-2Z—
EUR 14.89

Cheaper in larger quantities

from 5 pcsEUR 14.59−2%
from 10 pcsEUR 14.44−3%
from 25 pcsEUR 14.14−5%
from 50 pcsEUR 13.85−7%

Dispatched within 24 h from our own warehouse

Shipping within the EU: DHL, GLS, from EUR 13.18 net. Transit time 3–5 business days after dispatch. Shipping and returns →

Symbol (SKU)LFR5201-10-2Z#N1N
EAN4012802794342
Masa60 g

Buying for a company?

Open a business account →

Documentation

Datasheet (PDF)RoHS / REACH compliance declaration (PDF)

Opening a document for the first time can take up to a minute while the manufacturer prepares it.
