Description
Locknut HM
FAG
HM3080
Locknut
od EUR 1,427.57z VAT
netto EUR 1,160.63 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
HM3080—
EUR 1,427.57
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)HM3080#N1
EAN4012801218474
Masa18.70 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
17 parametersIdentification
- Manufacturer
- FAG
- Type
- Locknut
- Part number (SKU)
- HM3080#N1
- EAN
- 4012801218474
Dimensions
- Width B
- 52 mm
- Mass
- 18.70 kg
Full manufacturer specification11 parameters · expand
- Axial load capacity, static
- 5600000.0 N
- Chamfer angle
- 30.0 °
- Chamfer diameter
- 442.0 mm
- Fuse
- MS3076
- Height retaining slot
- 14.0 mm
- Outerside diameter
- 470.0 mm
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Thread
- Tr400X5
- Width retaining slot
- 28.0 mm
