Description
Adapter sleeve H..-HG, accessory rolling bearing, complete, hydraulic, FP
FAG
H2352X-HG
Adapter sleeve
⌀260 × 330 mm
od EUR 2,038.64z VAT
netto EUR 1,657.43 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
H2352X-HG—
EUR 2,038.64
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)H2352X-HG#N1
EAN4012801216838
Wymiary⌀260 × 330 mm
Masa25.80 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
20 parametersIdentification
- Manufacturer
- FAG
- Type
- Adapter sleeve
- Part number (SKU)
- H2352X-HG#N1
- EAN
- 4012801216838
Dimensions
- Bore d
- 260 mm
- Outside diameter D
- 330 mm
- Mass
- 25.80 kg
Full manufacturer specification13 parameters · expand
- Design
- HG
- Distance oil connector
- 4.2 mm
- Fuse
- MB52
- Locknut
- HM52T
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sleeve length
- 211.0 mm
- Taper
- 1:12
- Thread
- Tr260X4
- Thread depth oil connector
- 7.0 mm
- Thread oil connector
- M6
- Width nut and lock
- 38.0 mm
