Technical data
39 parametersIdentification
- Manufacturer
- INA
- Type
- Spherical plain bearing
- Part number (SKU)
- GE15-UK#N1
- EAN
- 4012802547542
Dimensions
- Bore d
- 15 mm
- Outside diameter D
- 26 mm
- Mass
- 26.15 g
Load ratings and operation
- Dynamic load rating C
- 17800 N
- Static load rating C₀
- 44600 N
- Sealing
- without
Full manufacturer specification29 parameters · expand
- Ball diameter
- 22.0 mm
- Bore diameter bearing, lower tolerance
- -0.008 mm
- Bore diameter bearing, upper tolerance
- 0.0 mm
- Bore lining
- without
- Coating
- without
- Connection measurement, inner ring
- 18.4 mm
- Edge Spacing
- 0.3 mm
- Fabric
- PTFE-composite
- Housing Connection Diameter
- 21.0 mm
- Inner ring width
- 12.0 mm
- Maintenance
- Maintenance free
- Material
- Steel
- Max. operating temperature
- 200.0 °C
- Min. operating temperature
- -50.0 °C
- Outer ring width
- 9.0 mm
- Outside diameter, lower tolerance
- -0.009 mm
- Outside diameter, upper tolerance
- 0.0 mm
- PFAS
- yes
- Radial Clearance
- 0 - 0,04
- Radial clearance, maximum
- 0.04 mm
- Radial clearance, minimum
- 0.0 mm
- REACH
- REACH compliant
- RoHS
- RoHS compliant
- Sealing
- without
- Tilt angle
- 8.0 °
- Width inner ring, lower tolerance
- -0.12 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width outer ring, lower tolerance
- -0.24 mm
- Width outer ring, upper tolerance
- 0.0 mm
Classification
- Manufacturer category
- Rolling and Plain Bearings › Plain Bearings › Spherical Plain Bearings › Spherical Plain Bearings, maintenance free
- eCl@ss class
- 23-05-01-06
- UNSPSC
- 31171515
Description
The GE15-UK is a radial spherical plain bearing designed for oscillating and tilting movements between the inner and outer ring. The sliding layer is made of PTFE composite, while the curved surface of the inner ring is finished with a hard chromium coating, giving a low-friction contact surface under load. The bearing is built according to DIN ISO 12240-1, dimension series E, in an open design, and its net mass is 26.15 g. Being maintenance-free, this plain bearing requires no relubrication during service, as the PTFE composite layer provides the necessary sliding properties without grease or oil. The open design, without sealing, means the bearing relies on a clean operating environment, since no seal protects the sliding surface from external contamination. The spherical form of the inner ring allows compensation of angular misalignment between shaft and housing.
The same bearing from other manufacturers (6 designations)
Same size and design — suffix notation differs between brands.
INA
GE15-UK
original — this page
equivalent designation
ASK
GE15-D
IKO
GE15EC
LS
GE15C
SKF
GE15C
SKF
GE15DC
SKF
GE15T
This is a dimensional and design equivalent, not the same product. If in doubt, ask us before ordering.
