Technical data

36 parameters

Identification

Manufacturer: INA
Type: Bush
Part number (SKU): EGB9060-E40-Y#N5
EAN: 4012802682076

Dimensions

Bore d: 90 mm
Outside diameter D: 95 mm
Width B: 60 mm
Mass: 322.84 g

Load ratings and operation

Dynamic load rating C: 756000 N
Static load rating C₀: 1350000 N
Sealing: without

Full manufacturer specification25 parameters · expand

Chamfer angle outside diameter: 20.0 °
Inner diameter, lower tolerance: 0.038 mm
Inner diameter, upper tolerance: 0.138 mm
Inner edge break: 0.2 mm
Inner edge break, max.: 1.0 mm
Inner edge break, min.: 0.2 mm
Maintenance: Maintenance free
Material back: Steel
Material sliding Layer: E40
Max. operating temperature: 280.0 °C
Min. operating temperature: -200.0 °C
Outer chamfer: 1.8 mm
Outer chamfer, lower tolerance: -0.6 mm
Outer chamfer, upper tolerance: 0.6 mm
Outside diameter, lower tolerance: 0.07 mm
Outside diameter, upper tolerance: 0.12 mm
PFAS: yes
REACH: REACH compliant
RoHS: RoHS compliant
Seal: without
Wall thickness: 2.5 mm
Wall thickness, lower tolerance: -0.06 mm
Wall thickness, upper tolerance: -0.01 mm
Width, lower tolerance: -0.25 mm
Width, upper tolerance: 0.25 mm

Classification

Manufacturer category: Rolling and Plain Bearings › Plain Bearings › Plain Bushes
eCl@ss class: 23-05-01-91
UNSPSC: 31171509

Description

This plain bush provides sliding support through a metal/polymer composite structure with a steel backing, built to ISO 3547. It has a width of 60.0 mm and a net mass of 322.84 g. The steel backing gives the bush its load-bearing rigidity, while the polymer sliding layer forms the actual running surface. Being maintenance-free, the EGB9060-E40-Y bush operates without external lubrication, as the polymer layer itself provides the sliding function. This construction makes it suitable for applications where relubrication access is limited or undesired, and where a steel-backed composite bush of this width and mass is required.
