Technical data
22 parametersIdentification
- Manufacturer
- INA
- Type
- Axial needle roller and cage assembly
- Part number (SKU)
- AXK160200-A/0-10#N
- EAN
- 4064328066274
Dimensions
- Outside diameter D
- 200 mm
- Mass
- 232 g
Load ratings and operation
- Dynamic load rating C
- 148000 N
- Static load rating C₀
- 1020000 N
- Limiting speed
- 1600 1/min
Full manufacturer specification13 parameters · expand
- Axial bearing washer
- AS160200
- Basic dynamic load rating, axial
- 148000.0 N
- Basic static load rating, axial
- 1020000.0 N
- Bore diameter cage
- 160.0 mm
- Fatigue load limit, axial
- 88000.0 N
- Max. operating temperature
- 120.0 °C
- Min. operating temperature
- -20.0 °C
- PFAS
- no
- Raceway dimension
- 166.0 mm
- REACH
- REACH compliant
- Reference speed
- 620.0 1/min
- RoHS
- RoHS compliant
- Rolling element diameter
- 5.0 mm
Classification
- Manufacturer category
- Rolling and Plain Bearings › Roller Bearings › Axial Needle Roller And Cage Assemblies
- eCl@ss class
- 23-05-11-90
- UNSPSC
- 31171512
Description
Axial needle roller and cage assemblies, single direction, to DIN 5405-2
For mounting this bearing
The sleeve, nut and lock washer needed to mount the bearing, followed by matching housings. All from our catalogue.
INA
AXK160200-A/0-10
Axial needle roller and cage assembly
od EUR 72.16net
+ VAT 23% = EUR 88.76 gross
Last few (2)dispatch within 24 h
AXK160200-A/0-10—
EUR 72.16
Cheaper in larger quantities
| from 5 pcs | EUR 70.72 | −2% |
| from 10 pcs | EUR 70.00 | −3% |
| from 25 pcs | EUR 68.56 | −5% |
| from 50 pcs | EUR 67.11 | −7% |
Dispatched within 24 h from our own warehouse
Shipping within the EU: DHL, GLS, from EUR 13.18 net. Transit time 3–5 business days after dispatch. Shipping and returns →
Symbol (SKU)AXK160200-A/0-10#N
EAN4064328066274
Masa232 g
Buying for a company?
Open a business account →Documentation
Datasheet (PDF)RoHS / REACH compliance declaration (PDF)Opening a document for the first time can take up to a minute while the manufacturer prepares it.
