- Basic dynamic load rating
- 18700.0 N
- Basic static load rating
- 10700.0 N
- Bearing designation
- GYE30-KRR-B-VA
- Bearing in kit
- SUC206
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Distance between mounting bolt centerlines (length)
- 90.5 mm
- Fatigue load limit, radial
- 530.0 N
- Fixing square
- 10.5 mm
- Height bearing seat
- 56.35 mm
- Height flange
- 112.7 mm
- Height housing
- 9.0 mm
- Housing
- FLAN62-MSB-VA
- Housing (Part 2)
- FLAN62-MSA-VA
- Housing height
- 112.7 mm
- Housing in kit
- GRRY30-VA
- Housing length
- 112.7 mm
- Housing material
- SB
- Housing opening
- durchgehend
- Housing qty bolts
- 3-4
- Housing shape
- Rund
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 38.1 mm
- Inner diameter bearing
- 30.0 mm
- Load carrying capacity (housing)
- 5000.0 N
- Location on shaft
- Acc
- Material
- VA
- Number of housings
- 1.0
- Number of housings 2
- 1.0
- Number of screwing holes
- 3.0
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -35.0 °C
- Outer diameter bearing
- 62.0 mm
- Outside diameter eccentric locking collar
- 44.0 mm
- PFAS
- nein
- Pitch circle diameter (holes)
- 90.5 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing type
- LIP
- Shoulder diameter housing
- 71.0 mm
- Special material
- VA
- Thickness of flange
- 2.5 mm
- Total height unit
- 24.7 mm
