Description
Cylindrical roller bearing SL02..-A, full complement roller set, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type SL02
INA
SL024924-A
Cylindrical roller bearing
⌀120 × 165 × 45 mm
od EUR 324.49z VAT
netto EUR 263.81 · cena detaliczna
SL024924-A—
EUR 324.49
Cheaper in larger quantities
| from 50 pcs | EUR 258.88 | −2% |
Last few (1)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)SL024924-A#N1
EAN4012802135060
Wymiary⌀120 × 165 × 45 mm
Masa2.80 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
33 parametersIdentification
- Manufacturer
- INA
- Type
- Cylindrical roller bearing
- Part number (SKU)
- SL024924-A#N1
- EAN
- 4012802135060
- Tolerance class
- PN
Dimensions
- Bore d
- 120 mm
- Outside diameter D
- 165 mm
- Width B
- 45 mm
- Mass
- 2.80 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 222000 N
- Static load rating C₀
- 440000 N
- Limiting speed
- 2260 1/min
Full manufacturer specification20 parameters · expand
- Axial displacement
- 3.0 mm
- Bearing designation DIN5412
- NNCL4924V
- Design
- A
- Distance to lubrication hole
- 22.5 mm
- Fatigue load limit, radial
- 56000.0 N
- Maximum recess radius
- 1.1 mm
- Maximum rib diameter inner ring
- 138.6 mm
- Minimum chamfer dimension
- 1.1 mm
- Minimum diameter of housing shoulder
- 153.5 mm
- Minimum diameter shaft shoulder
- 138.6 mm
- Minimum shaft shoulder
- 139.0 mm
- Number of rows
- 2
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- Raceway diameter outer ring
- 153.55 mm
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- Reference speed
- 1540.0 1/min
- RoHS
- RoHS compliant
