Description
Damping carriage, recirculating roller bearing unit
INA
RUDS55X300-D-H
Damping carriage, recirculating roller bearing unit
od EUR 1,526.38z VAT
netto EUR 1,240.96 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
RUDS55X300-D-H—
EUR 1,526.38
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)RUDS55X300-D-H#N1
EAN4054366207944
Masa11.60 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
18 parametersIdentification
- Manufacturer
- INA
- Type
- Damping carriage, recirculating roller bearing unit
- Part number (SKU)
- RUDS55X300-D-H#N1
- EAN
- 4054366207944
Dimensions
- Width B
- 98 mm
- Mass
- 11.60 kg
Full manufacturer specification12 parameters · expand
- Fixing screws
- M12
- Height
- 80.0 mm
- Length
- 300
- Number of fixing threads
- 8
- PFAS
- nein
- REACH
- REACH compliant for SVHC free linear products (acc to PL responsibles)
- Size code
- 55
- Standard length 3
- 300
- Suffix
- D
- Suitable linear guidances
- RUE55-E-H, RUE55-E-HL, RUE55-F-H, RUE55-F-HL
- Tightening torque
- 144.0 Nm
- Type
- H
