Description
Take-up housing unit RGVE
INA
RGVE40-FA106-FA137/SML
Take-up housing unit
od EUR 124.60z VAT
netto EUR 101.30 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
RGVE40-FA106-FA137/SML—
EUR 124.60
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)RGVE40-FA106-FA137/SML#N1
EAN4012802817010
Masa1.47 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
24 parametersIdentification
- Manufacturer
- INA
- Type
- Take-up housing unit
- Part number (SKU)
- RGVE40-FA106-FA137/SML#N1
- EAN
- 4012802817010
Dimensions
- Bore d
- 40 mm
- Mass
- 1.47 kg
Full manufacturer specification18 parameters · expand
- Bearing designation
- GE40-KRR-B-FA106-FA137
- Bearing sealed
- Yes
- Connection thread for lubrication
- M6
- Distance raceway
- 21.4 mm
- Height center point to top
- 67.0 mm
- Housing
- VE08
- Housing in kit
- RGVE40-FA106-FA137/SML
- Locking collar total width
- 56.5 mm
- Manufacturing instruction
- FA106
- Material
- GG
- Outside diameter eccentric locking collar
- 58.0 mm
- Outside diameter housing
- 100.0 mm
- PFAS
- nein
- REACH
- REACH compliant with declarable lead proportion
- RoHS
- RoHS compliant with declarable substances
- Thread depth
- 15.0 mm
- Thread fixing bore
- Rp3/8
- Width housing
- 26.0 mm
