Description
Radial insert ball bearing RABRN, with rubber interliner
INA
RABRN40/85-FA106
Radial insert ball bearing
⌀40 × 85 mm
od EUR 50.43z VAT
netto EUR 41.00 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
RABRN40/85-FA106—
EUR 50.43
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)RABRN40/85-FA106#N1
EAN4012802814354
Wymiary⌀40 × 85 mm
Masa840 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
23 parametersIdentification
- Manufacturer
- INA
- Type
- Radial insert ball bearing
- Part number (SKU)
- RABRN40/85-FA106#N1
- EAN
- 4012802814354
Dimensions
- Bore d
- 40 mm
- Outside diameter D
- 85 mm
- Mass
- 840 g
Load ratings and operation
- Dynamic load rating C
- 32500 N
- Static load rating C₀
- 19800 N
Full manufacturer specification14 parameters · expand
- Bearing designation
- GE40-KRR-B-FA106-FA137
- Distance raceway to locking collar
- 35.1 mm
- Flange diameter rubber interliner
- 70.0 mm
- Hardness rubber interliner
- 80.0 °
- Load carrying capacity (rubber interliner)
- 3500.0 N
- Locking collar total width
- 56.5 mm
- Manufacturing instruction
- FA106
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -20.0 °C
- Outside diameter locking collar/locknut
- 58.0 mm
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Width, outer ring
- 27.0 mm
