Description
Flanged housing unit RA..-XL
INA
RA50-XL-FA125.8
Flanged housing unit
⌀50 × 90 mm
od EUR 60.02z VAT
netto EUR 48.80 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
RA50-XL-FA125.8—
EUR 60.02
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)RA50-XL-FA125.8#N1
EAN4012802820539
Wymiary⌀50 × 90 mm
Masa1.60 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
57 parametersIdentification
- Manufacturer
- INA
- Type
- Flanged housing unit
- Part number (SKU)
- RA50-XL-FA125.8#N1
- EAN
- 4012802820539
Dimensions
- Bore d
- 50 mm
- Outside diameter D
- 90 mm
- Mass
- 1.60 kg
Load ratings and operation
- Dynamic load rating C
- 35000 N
- Static load rating C₀
- 23200 N
Full manufacturer specification48 parameters · expand
- Basic dynamic load rating
- 37500.0 N
- Basic static load rating
- 23200.0 N
- Bearing designation
- GRAE50-XL-NPP-B
- Bearing sealed
- Yes
- Bearing sort
- RIBB
- Bearing split
- No
- Distance between mounting bolt centerlines (length)
- 127.0 mm
- Fatigue load limit, radial
- 1090.0 N
- Fixing
- EXZ
- Fixing square
- 13.5 mm
- Flange width
- 155.5 mm
- Height bearing seat
- 77.75 mm
- Height flange
- 155.5 mm
- Height housing
- 11.1 mm
- Housing
- FLAN90-MSB-FA125
- Housing (Part 2)
- FLAN90-MSB
- Housing height
- 155.5 mm
- Housing in kit
- RA50-XL-FA125.8
- Housing length
- 155.5 mm
- Housing material
- SB
- Housing opening
- durchgehend
- Housing qty bolts
- 3-4
- Housing shape
- Rund
- Housing sort
- Flanged
- Housing split
- Nein
- Housing width
- 43.8 mm
- Inner diameter bearing
- 50.0 mm
- Load carrying capacity (housing)
- 8600.0 N
- Location on shaft
- Acc
- Locking collar total width
- 43.8 mm
- Manufacturing instruction
- FA125.8
- Marketing category
- XL
- Material
- Steel sheet
- Number of housings
- 2.0
- Number of screwing holes
- 4.0
- Number of screws
- 4.0
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -20.0 °C
- Outer diameter bearing
- 90.0 mm
- Outside diameter locking collar/locknut
- 69.0 mm
- PFAS
- nein
- Pitch circle diameter (holes)
- 127.0 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing type
- LIP
- Shoulder diameter housing
- 100.0 mm
- Thickness of flange
- 4.0 mm
- Total height unit
- 36.7 mm
