Description
Stud type track rollers PWKR..-2RS-XL, double row cylindrical roller bearings with particularly thick-walled outer ring, with a central rib, full complement cylindrical roller set and with a solid roller stud with fixing thread and a mounting aid, the outer ring is guided axially by the central rib and rolling elements, protected lip seal on both sides, without eccentric collar, X-life design
PWKR52-2RS-RR-XL
Stud type track roller
od EUR 164.81z VAT
netto EUR 133.99 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
Brought in to order — approx. 10 working days
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
39 parametersIdentification
- Manufacturer
- INA
- Type
- Stud type track roller
- Part number (SKU)
- PWKR52-2RS-RR-XL#N1
- EAN
- 4054366740601
Dimensions
- Outside diameter D
- 52 mm
- Width B
- 66 mm
- Mass
- 441 g
Load ratings and operation
- Dynamic load rating C
- 25500 N
- Static load rating C₀
- 33500 N
- Sealing
- 2RS
Full manufacturer specification29 parameters · expand
- Assembling aid head
- I6
- Assembling aid stud
- I6
- Bolt/stud length effectively
- 40.5 mm
- Coating
- RR
- Diameter lubrication hole
- 4.0 mm
- Distance to lubrication hole
- 9.0 mm
- Drive-fit lubrication nipple
- NIPA2X7,5
- Drive-fit lubrication nipple unmounted
- 2x
- Fatigue load limit, radial
- 4200.0 N
- Fit diameter of roller stud / stud
- 20.0 mm
- Marketing category
- XL
- Minimum chamfer dimension
- 1.0 mm
- Outer ring profile
- IOP
- Permissible dynamic load outer ring, radial
- 21800.0 N
- Permissible static load, radial
- 33500.0 N
- PFAS
- nein
- Protrusion outer ring to thrust washer
- 0.8 mm
- REACH
- REACH compliant with declarable lead proportion
- Relubrication
- KSP
- RoHS
- RoHS compliant with declarable substances
- Sealing
- 2RS
- Speed on permanent grease lubrication
- 3800.0 1/min
- Stop diameter of thrust washer
- 31.0 mm
- Thread
- M20X1,5
- Thread length
- 21.0 mm
- Tightening torque nut
- 120.0 Nm
- Width of flats
- 10.0 mm
- Width, outer ring
- 24.0 mm
- Witdh of thrust washer
- 25.6 mm
