Description
Linear roller bearings, inch size mounting dimensions, PR..
INA
PR14061-GR1/0-5
Linear recirculating roller bearing unit
od EUR 536.48z VAT
netto EUR 436.16 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
PR14061-GR1/0-5—
EUR 536.48
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)PR14061-GR1/0-5#N1
EAN4012802301267
Masa631 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
18 parametersIdentification
- Manufacturer
- INA
- Type
- Linear recirculating roller bearing unit
- Part number (SKU)
- PR14061-GR1/0-5#N1
- EAN
- 4012802301267
Dimensions
- Width B
- 38.1 mm
- Mass
- 631 g
Full manufacturer specification12 parameters · expand
- Adjustment gib
- VUSZ18059-A
- Height
- 28.6 mm
- Load capacity Dynamic
- 107000.0 N
- Load capacity static
- 175000.0 N
- Mounting Dimension
- 38.0 mm
- PFAS
- nein
- REACH
- REACH compliant for SVHC free linear products (acc to PL responsibles)
- Size Code
- 14061
- Size thread K3
- M4
- Suitable Guide Rail
- UG9741, UGN9741-A, UZ9741, UZN9741-A, UFK4710, UFB6412
- Tightening Torque fixing screws
- 5.0 Nm
- Tolerance
- 0.1 mm
