Description
Plain bearing unit, compact range
Schaeffler
LUHR12-PB
Linear plain bearing unit
od EUR 165.12z VAT
netto EUR 134.24 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
LUHR12-PB—
EUR 165.12
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)LUHR12-PB#N1
EAN4064331083053
Masa74 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
17 parametersIdentification
- Manufacturer
- Schaeffler
- Type
- Linear plain bearing unit
- Part number (SKU)
- LUHR12-PB#N1
- EAN
- 4064331083053
Dimensions
- Bore d
- 19 mm
- Mass
- 74 g
Full manufacturer specification11 parameters · expand
- Center height
- 17.0 mm
- Height
- 11.0 mm
- Height of Carriage
- 33.0 mm
- Length
- 28.0 mm
- Load capacity dyn
- 3350.0 N
- Load rating at 0.1 m/s
- 965.0 N
- Load rating at 4 m/s
- 24.0 N
- Number of seals
- 0
- REACH
- REACH conform
- Size code
- 12
- Thread
- M5
