Description
solid profile, with T-slot and lateral slots, with two raceway shafts; corrosion-resistant design possible
INA
LFS52X8000-NZZ-0020-EWL
Guideway
od EUR 1,248.28z VAT
netto EUR 1,014.86 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
LFS52X8000-NZZ-0020-EWL—
EUR 1,248.28
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)LFS52X8000-NZZ-0020-EWL#U
EAN4054372037894
Masa31.20 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
21 parametersIdentification
- Manufacturer
- INA
- Type
- Guideway
- Part number (SKU)
- LFS52X8000-NZZ-0020-EWL#U
- EAN
- 4054372037894
Dimensions
- Bore d
- 10 mm
- Width B
- 52 mm
- Mass
- 31.20 kg
Full manufacturer specification14 parameters · expand
- Cross-sectional area
- 994.0 mm²
- Depth
- 5.0 mm
- Diameter
- 10.0 mm
- Distance
- 16.8 mm
- Height
- 34.0 mm
- Increment
- 250.0 mm
- Length maximum
- 8000.0 mm
- PFAS
- nein
- REACH
- REACH compliant for SVHC free linear products (acc to PL responsibles)
- RoHS
- RoHS compliant
- Second moment of area
- 82786.0 mm⁴
- Size code
- 52
- Type
- NZZ
- Wider resistance torque
- 4927.0 mm³
