Description

Miniature-Carriage, Standard, with end wipers; for Miniature guideway, Standard

INA

KWEM07-E-PP-V1-G2

Name: KWEM07-E-PP-V1-G2
Brand: INA
SKU: KWEM07-E-PP-V1-G2#N1
Price: 50.16 EUR
Availability: BackOrder

Miniature Carriage, Standard for Miniature-Guideway, Standard

od EUR 50.16z VAT

netto EUR 40.78 · cena detaliczna

This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.

KWEM07-E-PP-V1-G2—

EUR 50.16

To orderapprox. 10 days

Brought in to order — approx. 10 working days

Symbol (SKU)KWEM07-E-PP-V1-G2#N1

EAN4064328500624

Masa12 g

Buying for a company?

A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.

32 parameters

Full manufacturer specification26 parameters · expand

Accuracy class: G2
Basic static load capacity: 1460.0 N
Carriage design: /
Distance from locating edge on carriage to locating edge on guideway: 5.0 mm
Distance from locating edge to hole: 2.5 mm
Dynamic load rating: 915.0 N
Free space, system dimension: 1.5 mm
Height system: 8.0 mm
Hole spacing: 12.0 mm
Hole Spacing: 8.0 mm
Length of carriage: 23.5 mm
Material name: KWEM
Maximum tightening torque: 0.32 Nm
Position lubrication connector: 1.7 mm
Preload class: V1
REACH: REACH compliant for SVHC free linear products (acc to PL responsibles)
Seal: PP
Size code: 07
Static moment rating about X axis: 4.6 Nm
Static moment rating about Y axis: 2.6 Nm
Static moment rating about Z axis: 2.6 Nm
Thread depth: 2.5 mm
Thread size: M2
Version: E
Width carriage: 17.0 mm
Width rail: 7.0 mm
