Product photo

Description

Stud type track rollers KRE..-PP-A, single row needle roller bearings with particularly thick-walled outer ring, needle roller and cage assembly and a solid roller stud with fixing thread and a mounting aid, axial guidance of outer ring is provided by the plastic axial plain washers, contact flange and contact washer, three-stage sealing by plastic axial plain washer on both sides, with eccentric collar

INA

KRE19-PP-A-NMT

Stud type track roller

od EUR 51.32z VAT

netto EUR 41.72 · cena detaliczna

This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.

KRE19-PP-A-NMT
EUR 51.32
To orderapprox. 10 days

Brought in to order — approx. 10 working days

Symbol (SKU)KRE19-PP-A-NMT#N1
EAN4047643178846
Masa36.219 g

Buying for a company?

A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.

Open a business account

Technical data

35 parameters

Identification

Manufacturer
INA
Type
Stud type track roller
Part number (SKU)
KRE19-PP-A-NMT#N1
EAN
4047643178846

Dimensions

Outside diameter D
19 mm
Width B
32 mm
Mass
36.219 g

Load ratings and operation

Dynamic load rating C
3550 N
Static load rating C₀
4100 N
Sealing
PP
Full manufacturer specification25 parameters · expand
Assembling aid head
SL
Bolt/stud length effectively
20.0 mm
Diameter of eccentric
11.0 mm
Drive-fit lubrication nipple
NIPA1
Drive-fit lubrication nipple unmounted
1x
Eccentricity
0.5 mm
Fatigue load limit, radial
560.0 N
Fit diameter of roller stud / stud
8.0 mm
Minimum chamfer dimension
0.15 mm
Outer ring profile
IOP
PFAS
nein
Protrusion lubrication nipple
1.5 mm
Protrusion outer ring to thrust washer
0.6 mm
REACH
REACH compliant with declarable lead proportion
RoHS
RoHS compliant with declarable substances
Sealing
PP
Special shape
NMT
Speed on permanent grease lubrication
11000.0 1/min
Stop diameter of thrust washer
15.0 mm
Thread
M8
Thread length
10.0 mm
Tightening torque nut
8.0 Nm
Width, eccentric
9.0 mm
Width, outer ring
11.0 mm
Witdh of thrust washer
12.2 mm
