Product photo

Description

Stud type track rollers KR..-SK-PP-A, single row needle roller bearings with particularly thick-walled outer ring, needle roller and cage assembly and a solid roller stud with fixing thread and a mounting aid, axial guidance of outer ring is provided by the plastic axial plain washers, contact flange and contact washer, three-stage sealing by plastic axial plain washer on both sides, without eccentric collar, assembling aid hexagonal socket only on the flange side end face, no relubrication facility

INA

KR16-SK-PP-A-NMT

Stud type track roller

od EUR 42.14z VAT

netto EUR 34.26 · cena detaliczna

This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.

KR16-SK-PP-A-NMT
EUR 42.14
To orderapprox. 10 days

Brought in to order — approx. 10 working days

Symbol (SKU)KR16-SK-PP-A-NMT#N1
EAN4054362445494
Masa20 g

Buying for a company?

A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.

Open a business account

Technical data

33 parameters

Identification

Manufacturer
INA
Type
Stud type track roller
Part number (SKU)
KR16-SK-PP-A-NMT#N1
EAN
4054362445494

Dimensions

Outside diameter D
16 mm
Mass
20 g

Load ratings and operation

Dynamic load rating C
3200 N
Static load rating C₀
3450 N
Sealing
PP
Full manufacturer specification24 parameters · expand
Assembling aid head
SK
Bolt/stud length effectively
16.0 mm
Drive-fit lubrication nipple unmounted
Without
Fatigue load limit, radial
465.0 N
Fit diameter of roller stud / stud
6.0 mm
Maximum witdh of thrust washer
12.2 mm
Minimum chamfer dimension
0.15 mm
Outer ring profile
IOP
PFAS
nein
Protrusion outer ring to thrust washer
0.6 mm
Radius of outer ring outside profile
500.0 mm
REACH
REACH conform
Relubrication
Without
RoHS
RoHS compliant
Sealing
PP
Special Shape
NMT
Speed on permanent grease lubrication
14000.0 1/min
Stop diameter of thrust washer
12.5 mm
Thread
M6
Thread length
8.0 mm
Tightening torque nut
3.0 Nm
Width of flats
4.0 mm
Width of the roller stud
28.0 mm
Width, outer ring
11.0 mm
