Description
Linear ball bearings KNO..-B-PP, Lightweight range, open design, sealed on all sides, with relubrication facility, adjustable angle
INA
KNO12-B-PP
Linear Ball Bearing
⌀12 × 22 mm
od EUR 25.84z VAT
netto EUR 21.01 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
KNO12-B-PP—
EUR 25.84
Cheaper in larger quantities
| from 25 pcs | EUR 19.96 | −5% |
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)KNO12-B-PP#N1
EAN4012802471229
Wymiary⌀12 × 22 mm
Masa20 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
19 parametersIdentification
- Manufacturer
- INA
- Type
- Linear Ball Bearing
- Part number (SKU)
- KNO12-B-PP#N1
- EAN
- 4012802471229
Dimensions
- Bore d
- 12 mm
- Outside diameter D
- 22 mm
- Mass
- 20 g
Load ratings and operation
- Sealing
- PP
Full manufacturer specification11 parameters · expand
- Angle of sector opening
- 66.0 °
- Length
- 32.0 mm
- Load capacity dyn.
- 840.0 N
- Load capacity stat.
- 640.0 N
- Number of rows balls
- 4
- PFAS
- nein
- REACH
- REACH compliant for SVHC free linear products (acc to PL responsibles)
- RoHS
- RoHS compliant
- Seal
- PP
- Size Code
- 12
- Width of sector opening
- 6.5 mm
