Description
Axial cylindrical roller and cage assembly K811, single direction, suitable for combination with axial bearing washers
INA
K81120-TV/0-8
Axial cyl roller and cage assy -LS
od EUR 80.69z VAT
netto EUR 65.60 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
K81120-TV/0-8—
EUR 80.69
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)K81120-TV/0-8#N1>1
EAN4047643177399
Masa241 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
24 parametersIdentification
- Manufacturer
- INA
- Type
- Axial cyl roller and cage assy -LS
- Part number (SKU)
- K81120-TV/0-8#N1>1
- EAN
- 4047643177399
- Cage
- TV
- Tolerance class
- 0-8
Dimensions
- Mass
- 241 g
Load ratings and operation
- Dynamic load rating C
- 199000 N
- Static load rating C₀
- 650000 N
- Limiting speed
- 2450 1/min
Full manufacturer specification14 parameters · expand
- Basic dynamic load rating, axial
- 199000.0 N
- Basic static load rating, axial
- 650000.0 N
- Bore diameter cage
- 100.0 mm
- Cage
- TV
- Cage outer diameter
- 135.0 mm
- Fatigue load limit, axial
- 60000.0 N
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- Raceway dimension
- 104.0 mm
- REACH
- REACH conform
- Reference speed
- 920.0 1/min
- RoHS
- RoHS compliant
- Rolling element diameter
- 11.0 mm
