Description
Drawn cup needle roller bearings with open ends HN, full complement needle roller set
INA
HN0808
Drawn cup needle roller bearing open end
od EUR 3.06z VAT
netto EUR 2.49 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
HN0808—
EUR 3.06
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)HN0808#N245
EAN4054369015201
Opakowanie245 szt.
Minimum order245 szt.
Masa3.1 g
Ten towar sprzedawany jest w opakowaniach po 245 szt.
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
20 parametersIdentification
- Manufacturer
- INA
- Type
- Drawn cup needle roller bearing open end
- Part number (SKU)
- HN0808#N245
- EAN
- 4054369015201
Dimensions
- Outside diameter D
- 12 mm
- Mass
- 3.1 g
Load ratings and operation
- Dynamic load rating C
- 5000 N
- Static load rating C₀
- 6700 N
Full manufacturer specification12 parameters · expand
- Fatigue load limit, radial
- 880.0 N
- Limiting speed for grease lubrication
- 12700.0 1/min
- Lubricant
- L563
- Minimum chamfer dimension
- 0.4 mm
- Operating temperature max.
- 140.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- REACH
- REACH conform
- Reference speed
- 18000.0 1/min
- RoHS
- RoHS compliant
- Under roller diameter
- 8.0 mm
- Width, outer ring
- 8.0 mm
