Description
Radial insert ball bearings GSH..-2RSR-B, spherical outer ring, location by adapter sleeve, RSR seals on both sides
INA
GSH25-XL-2RSR-B
Radial insert ball bearing
od EUR 33.67z VAT
netto EUR 27.37 · cena detaliczna
GSH25-XL-2RSR-B—
EUR 33.67
Cheaper in larger quantities
| from 250 pcs | EUR 26.00 | −5% |
Last few (3)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)GSH25-XL-2RSR-B#N1
EAN4012802816174
Masa160 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
27 parametersIdentification
- Manufacturer
- INA
- Type
- Radial insert ball bearing
- Part number (SKU)
- GSH25-XL-2RSR-B#N1
- EAN
- 4012802816174
Dimensions
- Outside diameter D
- 52 mm
- Width B
- 15 mm
- Mass
- 160 g
Load ratings and operation
- Dynamic load rating C
- 13600 N
- Static load rating C₀
- 7800 N
- Sealing
- 2RSR
Full manufacturer specification17 parameters · expand
- Adapter sleeve
- HUESH.SH25-ZN-0100-HLA
- Calculation factor
- 13.9
- Distance raceway
- 7.5 mm
- Distance to lubrication hole
- 3.9 mm
- Fatigue load limit, radial
- 420.0 N
- Hight retaining slot adapter sleeve
- 5.0 mm
- Inner diameter of sleeve
- 25.0 mm
- Marketing category
- XL
- Outside diameter locking collar/locknut
- 38.0 mm
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- 2RSR
- Shape of outer surface
- B
- Total width of bearing
- 28.0 mm
- Width retaining slot
- 5.0 mm
- Width, outer ring
- 15.0 mm
