Description
Rod end with internal thread, maintenance-free, sliding layer: ELGOGLIDE, DIN ISO 12240-4, dimension series E, type F, inner ring curved surface with hard chromium coating, sealed, right hand thread
INA
GIR30-UK-2RS-A
Rod end
⌀30 × 47 mm
od EUR 127.51z VAT
netto EUR 103.67 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GIR30-UK-2RS-A—
EUR 127.51
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GIR30-UK-2RS-A#N1
EAN4012802528893
Wymiary⌀30 × 47 mm
Masa970 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
45 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GIR30-UK-2RS-A#N1
- EAN
- 4012802528893
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 47 mm
- Mass
- 970 g
Load ratings and operation
- Dynamic load rating C
- 165000 N
- Static load rating C₀
- 139000 N
- Sealing
- 2RS
Full manufacturer specification35 parameters · expand
- Ball diameter
- 40.7 mm
- Bore diameter bearing, lower tolerance
- -0.01 mm
- Bore diameter bearing, upper tolerance
- 0.0 mm
- Clampable
- Not clampable
- Distance drilling with/shaft start
- 37.0 mm
- Edge Spacing
- 0.6 mm
- Length rod end shank
- 15.0 mm
- Lubrication nipple
- Cannot be relubricated
- Maintenance
- Maintenance free
- Mounting
- Internal thread
- Operating temperature max.
- 130.0 °C
- Operating temperature min.
- -30.0 °C
- Outer eye diameter
- 73.0 mm
- Outer flange diameter inner ring
- 34.2 mm
- PFAS
- ja
- Radial Clearance
- 0 - 0,05
- Radial clearance, maximum
- 0.05 mm
- Radial clearance, minimum
- 0.0 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- 2RS
- Shank diameter
- 40.0 mm
- Shank diameter, large
- 50.0 mm
- Shank Length Internal thread head
- 110.0 mm
- Slotted
- No
- Thread length Internal thread
- 56.0 mm
- Thread Pitch
- Right-hand thread
- Thread size
- M30x2
- Tilt angle
- 6.0 °
- Total length internal thread head
- 146.5 mm
- Width Across Flat
- 41.0 mm
- Width inner ring
- 22.0 mm
- Width inner ring, lower tolerance
- -0.12 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width of the rod end
- 19.0 mm
