Description
Rod end with internal thread, left hand thread, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-4, dimension series E, type F, sealed
INA
GIL70-DO-2RS-C
Rod end
⌀70 × 105 mm
od EUR 880.72z VAT
netto EUR 716.03 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GIL70-DO-2RS-C—
EUR 880.72
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GIL70-DO-2RS-C#N1
EAN4064328482449
Wymiary⌀70 × 105 mm
Masa8.70 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
47 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GIL70-DO-2RS-C#N1
- EAN
- 4064328482449
Dimensions
- Bore d
- 70 mm
- Outside diameter D
- 105 mm
- Mass
- 8.70 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 407000 N
- Static load rating C₀
- 547000 N
- Sealing
- 2RS
Full manufacturer specification36 parameters · expand
- Ball diameter
- 92.0 mm
- Bore diameter bearing, lower tolerance
- -0.015 mm
- Bore diameter bearing, upper tolerance
- 0.0 mm
- Clampable
- Not clampable
- Distance drilling with/shaft start
- 87.0 mm
- Edge Spacing
- 1.0 mm
- Length rod end shank
- 20.0 mm
- Lubrication nipple
- DIN71412-AM6 (tapered grease nipple)
- Maintenance
- Maintenance required
- Mounting
- Internal thread
- Operating temperature max.
- 130.0 °C
- Operating temperature min.
- -30.0 °C
- Outer eye diameter
- 160.0 mm
- Outer flange diameter inner ring
- 77.9 mm
- PFAS
- nein
- Radial Clearance
- 0,055 - 0,142
- Radial clearance, maximum
- 0.142 mm
- Radial clearance, minimum
- 0.055 mm
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- 2RS
- Shank diameter
- 80.0 mm
- Shank diameter, large
- 98.0 mm
- Shank Length Internal thread head
- 200.0 mm
- Slotted
- No
- Thread length Internal thread
- 80.0 mm
- Thread Pitch
- Left-hand thread
- Thread size
- M56X4
- Tilt angle
- 6.0 °
- Total length internal thread head
- 280.0 mm
- Width Across Flat
- 85.0 mm
- Width inner ring
- 49.0 mm
- Width inner ring, lower tolerance
- -0.15 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width of the rod end
- 42.0 mm
