Description
Hydraulic rod end, with thread clamping device, right hand thread, requiring maintenance, sliding contact surface: steel/steel, open design
INA
GIHRK60-DO-A
Rod end
⌀60 × 90 mm
od EUR 306.22z VAT
netto EUR 248.96 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GIHRK60-DO-A—
EUR 306.22
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GIHRK60-DO-A#N1
EAN4012802525731
Wymiary⌀60 × 90 mm
Masa5.62 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
47 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GIHRK60-DO-A#N1
- EAN
- 4012802525731
Dimensions
- Bore d
- 60 mm
- Outside diameter D
- 90 mm
- Mass
- 5.62 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 318000 N
- Static load rating C₀
- 327000 N
- Sealing
- Without
Full manufacturer specification36 parameters · expand
- Ball diameter
- 80.0 mm
- Bore diameter bearing, lower tolerance
- -0.015 mm
- Bore diameter bearing, upper tolerance
- 0.0 mm
- Clampable
- Clampable
- Diameter screw clamp
- M10x45
- Distance drilling with/shaft start
- 65.0 mm
- Edge Spacing
- 1.0 mm
- Lubrication nipple
- DIN71412-AS6 (tapered grease nipple)
- Maintenance
- Maintenance required
- Mounting
- Internal thread clampable
- Operating temperature max.
- 200.0 °C
- Operating temperature min.
- -60.0 °C
- Outer eye diameter
- 130.0 mm
- Outer flange diameter inner ring
- 66.8 mm
- PFAS
- nein
- Radial Clearance
- 0,043 - 0,12
- Radial clearance, maximum
- 0.12 mm
- Radial clearance, minimum
- 0.043 mm
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- Without
- Shank diameter
- 75.0 mm
- Shank diameter, large
- 90.0 mm
- Shank Length Internal thread head
- 130.0 mm
- Slotted
- Slotted, both sides
- Thread length Internal thread
- 59.0 mm
- Thread Pitch
- Right-hand thread
- Thread size
- M58x1,5
- Tightening torque
- 46.0 Nm
- Tilt angle
- 6.0 °
- Total length internal thread head
- 200.0 mm
- Width inner ring
- 44.0 mm
- Width inner ring, lower tolerance
- -0.15 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width of the rod end
- 50.0 mm
