Description
Hydraulic rod end, with thread clamping device, right hand thread, requiring maintenance, sliding contact surface: steel/steel, DIN 24338 ISO 6982, open design
INA
GIHNRK160-LO-C
Rod end
⌀160 × 230 × 82 mm
od EUR 8,039.24z VAT
netto EUR 6,535.97 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GIHNRK160-LO-C—
EUR 8,039.24
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GIHNRK160-LO-C#N1N
EAN4064328243316
Wymiary⌀160 × 230 × 82 mm
Masa82.00 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
50 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GIHNRK160-LO-C#N1N
- EAN
- 4064328243316
Dimensions
- Bore d
- 160 mm
- Outside diameter D
- 230 mm
- Width B
- 82 mm
- Mass
- 82.00 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 1770000 N
- Static load rating C₀
- 2580000 N
- Sealing
- Without
Full manufacturer specification38 parameters · expand
- Ball diameter
- 200.0 mm
- Bore diameter bearing, lower tolerance
- 0.0 mm
- Bore diameter bearing, tolerance
- H7
- Bore diameter bearing, upper tolerance
- 0.04 mm
- Clampable
- Clampable
- Cylinder Force
- 1250000.0 N
- Diameter screw clamp
- M24x80
- Distance drilling with/shaft start
- 150.0 mm
- Edge Spacing
- 1.0 mm
- Lubrication nipple
- DIN71412-AM6 (tapered grease nipple)
- Maintenance
- Maintenance required
- Mounting
- Internal thread clampable
- Operating temperature max.
- 200.0 °C
- Operating temperature min.
- -60.0 °C
- Outer eye diameter
- 326.0 mm
- Outer flange diameter inner ring
- 177.0 mm
- PFAS
- nein
- Radial Clearance
- CN
- Radial clearance, maximum
- 0.192 mm
- Radial clearance, minimum
- 0.05 mm
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- Without
- Shank diameter
- 165.0 mm
- Shank diameter, large
- 250.0 mm
- Shank Length Internal thread head
- 310.0 mm
- Slotted
- Slotted, one side
- Thread length Internal thread
- 126.0 mm
- Thread Pitch
- Right-hand thread
- Thread size
- M125x4
- Tightening torque
- 660.0 Nm
- Tilt angle
- 4.0 °
- Total length internal thread head
- 488.0 mm
- Width inner ring
- 160.0 mm
- Width inner ring, lower tolerance
- -0.4 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width of the rod end
- 130.0 mm
