Description
Hydraulic rod end, with thread clamping device, right hand thread, requiring maintenance, sliding contact surface: steel/steel, DIN 24338 ISO 6982, open design
INA
GIHNRK100-LO-B
Rod end
⌀100 × 150 × 62 mm
od EUR 1,164.16z VAT
netto EUR 946.47 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GIHNRK100-LO-B—
EUR 1,164.16
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GIHNRK100-LO-B#N1
EAN4012802525458
Wymiary⌀100 × 150 × 62 mm
Masa23.80 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
48 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GIHNRK100-LO-B#N1
- EAN
- 4012802525458
Dimensions
- Bore d
- 100 mm
- Outside diameter D
- 150 mm
- Width B
- 62 mm
- Mass
- 23.80 kg
Load ratings and operation
- Dynamic load rating C
- 790000 N
- Static load rating C₀
- 840000 N
- Sealing
- Without
Full manufacturer specification37 parameters · expand
- Ball diameter
- 130.0 mm
- Bore diameter bearing, lower tolerance
- 0.0 mm
- Bore diameter bearing, tolerance
- H7
- Bore diameter bearing, upper tolerance
- 0.035 mm
- Clampable
- Clampable
- Cylinder Force
- 500000.0 N
- Diameter screw clamp
- M20x60
- Distance drilling with/shaft start
- 98.0 mm
- Edge Spacing
- 1.0 mm
- Lubrication nipple
- DIN71412-AS6 (tapered grease nipple)
- Maintenance
- Maintenance required
- Mounting
- Internal thread
- Operating temperature max.
- 200.0 °C
- Operating temperature min.
- -60.0 °C
- Outer eye diameter
- 210.0 mm
- Outer flange diameter inner ring
- 113.0 mm
- PFAS
- nein
- Radial Clearance
- 0,065 - 0,165
- Radial clearance, maximum
- 0.165 mm
- Radial clearance, minimum
- 0.065 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- Without
- Shank diameter
- 110.0 mm
- Shank diameter, large
- 178.0 mm
- Shank Length Internal thread head
- 210.0 mm
- Slotted
- Slotted, one side
- Thread length Internal thread
- 96.0 mm
- Thread Pitch
- Right-hand thread
- Thread size
- M80x3
- Tightening torque
- 385.0 Nm
- Tilt angle
- 4.0 °
- Total length internal thread head
- 322.0 mm
- Width inner ring
- 100.0 mm
- Width inner ring, lower tolerance
- -0.35 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width of the rod end
- 84.0 mm
