Description
Hydraulic rod end, with thread clamping device, left hand thread, requiring maintenance, sliding contact surface: steel/steel, open design
INA
GIHLK80-DO-C
Rod end
⌀80 × 120 mm
od EUR 610.06z VAT
netto EUR 495.98 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GIHLK80-DO-C—
EUR 610.06
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GIHLK80-DO-C#N1
EAN4064327809551
Wymiary⌀80 × 120 mm
Masa14.60 kg
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
48 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GIHLK80-DO-C#N1
- EAN
- 4064327809551
Dimensions
- Bore d
- 80 mm
- Outside diameter D
- 120 mm
- Mass
- 14.60 kg
- Radial clearance
- CN (Group N)
Load ratings and operation
- Dynamic load rating C
- 522000 N
- Static load rating C₀
- 670000 N
- Sealing
- Without
Full manufacturer specification37 parameters · expand
- Ball diameter
- 105.0 mm
- Bore diameter bearing, lower tolerance
- 0.0 mm
- Bore diameter bearing, tolerance
- H7
- Bore diameter bearing, upper tolerance
- 0.03 mm
- Clampable
- Clampable
- Diameter screw clamp
- M20x55
- Distance drilling with/shaft start
- 80.0 mm
- Edge Spacing
- 1.0 mm
- Lubrication nipple
- DIN71412-AM6 (tapered grease nipple)
- Maintenance
- Maintenance required
- Mounting
- Internal thread
- Operating temperature max.
- 200.0 °C
- Operating temperature min.
- -60.0 °C
- Outer eye diameter
- 176.0 mm
- Outer flange diameter inner ring
- 89.4 mm
- PFAS
- nein
- Radial Clearance
- CN
- Radial clearance, maximum
- 0.142 mm
- Radial clearance, minimum
- 0.055 mm
- Radial internal clearance
- CN (Group N)
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- Without
- Shank diameter
- 105.0 mm
- Shank diameter, large
- 160.0 mm
- Shank Length Internal thread head
- 170.0 mm
- Slotted
- Slotted, both sides
- Thread length Internal thread
- 80.0 mm
- Thread Pitch
- Left-hand thread
- Thread size
- M80x2
- Tightening torque
- 535.0 Nm
- Tilt angle
- 6.0 °
- Total length internal thread head
- 265.0 mm
- Width inner ring
- 55.0 mm
- Width inner ring, lower tolerance
- -0.03 mm
- Width inner ring, upper tolerance
- 0.0 mm
- Width of the rod end
- 60.0 mm
