INA
GE30-KRR-B-FA107-VA-FD
Radial insert ball bearing
⌀30 × 62 × 23.8 mm
od EUR 95.42z VAT
netto EUR 77.58 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GE30-KRR-B-FA107-VA-FD—
EUR 95.42
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GE30-KRR-B-FA107-VA-FD#N1
EAN4064328588684
Wymiary⌀30 × 62 × 23.8 mm
Masa300 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
28 parametersIdentification
- Manufacturer
- INA
- Type
- Radial insert ball bearing
- Part number (SKU)
- GE30-KRR-B-FA107-VA-FD#N1
- EAN
- 4064328588684
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 62 mm
- Width B
- 23.8 mm
- Mass
- 300 g
Load ratings and operation
- Dynamic load rating C
- 19460 N
- Static load rating C₀
- 11310 N
- Sealing
- KRR
Full manufacturer specification17 parameters · expand
- Calculation factor
- 13.8
- Distance raceway
- 8.0 mm
- Distance to lubrication hole
- 5.0 mm
- Fatigue load limit, radial
- 475.0 N
- Locking collar total width
- 35.7 mm
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -30.0 °C
- Outside diameter locking collar/locknut
- 44.5 mm
- PFAS
- nein
- REACH
- REACH conform
- Rib diameter inner ring
- 40.3 mm
- RoHS
- RoHS compliant
- Sealing
- KRR
- Shape of outer surface
- B
- Special material
- VA
- Width of flats
- 3.0 mm
- Width, outer ring
- 16.0 mm
