Description
Radial insert ball bearing GE..-XL-KTT-B-OSE
INA
GE25-XL-KTT-B-L402/70-OSE
Radial insert ball bearing
⌀25 × 52 × 34.9 mm
od EUR 31.18z VAT
netto EUR 25.35 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GE25-XL-KTT-B-L402/70-OSE—
EUR 31.18
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GE25-XL-KTT-B-L402/70-OSE#N1
EAN4064327238016
Wymiary⌀25 × 52 × 34.9 mm
Masa185 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
28 parametersIdentification
- Manufacturer
- INA
- Type
- Radial insert ball bearing
- Part number (SKU)
- GE25-XL-KTT-B-L402/70-OSE#N1
- EAN
- 4064327238016
Dimensions
- Bore d
- 25 mm
- Outside diameter D
- 52 mm
- Width B
- 34.9 mm
- Mass
- 185 g
Load ratings and operation
- Dynamic load rating C
- 14900 N
- Static load rating C₀
- 7800 N
- Sealing
- KTT
Full manufacturer specification17 parameters · expand
- Calculation factor
- 13.8
- Distance raceway
- 17.5 mm
- Distance to lubrication hole
- 3.9 mm
- Lubricant
- L402/70
- Marketing category
- XL
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -20.0 °C
- Outside diameter seal
- 42.5 mm
- PFAS
- nein
- REACH
- REACH_YES_115-86-6_597-82-0!
- Rib diameter inner ring
- 33.821 mm
- RoHS
- RoHS compliant
- Sealing
- KTT
- Sealing total width
- 21.4 mm
- Shape of outer surface
- B
- Width, outer ring
- 15.0 mm
- Without locking device
- OSE
