Description
Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design
INA
GAL15-UK
Rod end
⌀15 × 26 mm
od EUR 40.91z VAT
netto EUR 33.26 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
GAL15-UK—
EUR 40.91
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)GAL15-UK#N1
EAN4012802524741
Wymiary⌀15 × 26 mm
Masa150 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
41 parametersIdentification
- Manufacturer
- INA
- Type
- Rod end
- Part number (SKU)
- GAL15-UK#N1
- EAN
- 4012802524741
Dimensions
- Bore d
- 15 mm
- Outside diameter D
- 26 mm
- Mass
- 150 g
Load ratings and operation
- Sealing
- Without
Full manufacturer specification33 parameters · expand
- Ball diameter
- 22.0 mm
- Basic dynamic load rating
- 17800.0 N
- Basic static load rating
- 41600.0 N
- Bore diameter bearing upper tolerance
- 0.0 mm
- Bore diameter, lower tolerance
- -0.008 mm
- Clampable
- Not clampable
- Length of the flat surface from the bearing bore centre to the shank
- 20.0 mm
- Length of thread
- 63.0 mm
- Lubrication nipple
- Cannot be relubricated
- Maintenance
- Maintenance free
- Mounting
- External thread
- Operating temperature max.
- 200.0 °C
- Operating temperature min.
- -50.0 °C
- Outer diameter eye
- 40.0 mm
- Outer flange diameter inner ring
- 18.4 mm
- PFAS
- ja
- Radial clearance
- 0 - 0,04
- Radial clearance, maximum
- 0.04 mm
- Radial clearance, minimum
- 0.0 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Sealing
- Without
- Slotted
- No
- Smallest single chamfer dimension, inner ring
- 0.3 mm
- Thread length
- 34.0 mm
- Thread Pitch
- Left-hand thread
- Thread size
- M14
- Tilt angle
- 8.0 °
- Total length
- 83.0 mm
- Width inner ring
- 12.0 mm
- Width inner ring , lower tolerance
- -0.12 mm
- Width inner ring; upper tolerance
- 0.0 mm
- Width of the rod end
- 10.0 mm
